Zebra ZT510 300Dpi Industrial Printer || Smart Printing Solutions Ltd.

The Zebra ZT510 300 dpi Industrial Label Printer combines rugged durability with advanced performance, making it the ideal choice for demanding industrial environments. Engineered to handle diverse applications, it delivers sharp, high-resolution prints with precision and speed, ensuring reliable output for manufacturing, transportation, logistics, retail, and beyond.

Equipped with versatile connectivity options, the ZT510 includes Ethernet, Serial, USB, dual USB Host, and Bluetooth 4.1 as standard. For enhanced flexibility, an optional dual-band wireless card with 802.11ac Wi-Fi and Bluetooth can be added for fast and reliable wireless communication.

Expand functionality with field- or factory-installable RFID technology, allowing you to print and encode RFID labels for improved asset tracking and visibility. The ZT510 is capable of handling thicker RFID labels, including those designed for metal containers and assets.

Feature	Description
Print Technology	Thermal Transfer and Direct Thermal printing modes.
Print Width	Up to 4.09 inches (104 mm), suitable for various industrial label sizes.
Print Speed	Up to 12 inches per second (ips), ensuring fast and efficient output.
Print Resolution	300 dpi for sharp, high-quality text, barcodes, and graphics, perfect for detailed applications.
Media Handling	Supports continuous, die-cut, black-mark, notch, and fanfold media.
Ribbon Capacity	Supports ribbons up to 450 meters for extended use and reduced downtime.
User Interface	Simplified interface with an LCD screen and keypad for easy navigation.
Connectivity Options	Includes USB, Serial, Gigabit Ethernet, and Bluetooth as standard; optional Wi-Fi available.
Durable Construction	All-metal frame and bi-fold door for rugged and reliable performance in industrial environments.
Environmental Tolerance	Designed to withstand extreme temperatures, dust, and harsh conditions.
Applications	Ideal for asset management, work-in-process tracking, compliance labeling, and distribution.
Software Compatibility	Compatible with Zebra's Link-OS, ZPL, and EPL programming languages for seamless integration.
Energy Efficiency	ENERGY STAR certified for reduced energy consumption and eco-friendly operation.
Advanced Features	Real-time clock for time-stamped labels and advanced diagnostics for proactive maintenance.
Field Upgradeable	Expandable options like peelers and cutters to adapt to evolving business requirements.

General

Display	LCD Display
Power	Auto-detectable (PFC Compliant) 90-265 VAC, 47-63Hz, rated at 250 Watts
Dimensions	268.2 x 395.68 x 512.3mm

Print

Print Speed	305 mm/sec
Print Resolution	203 dpi

Paper Handling

Paper Size	114 mm Length: 0.25 Inch/6 mm (Rewind mode), 0.5 Inch/13 mm (Peel mode), 0.7 Inch/18 mm (Tear-off mode), 1.5 Inch/38 mm (Cutter mode)
Paper Type	Continuous, die-cut, notch, black-mark
